DHS-16A Halogen Moisture Analyzer
If you have any questions, please contact us immediately.
Similar products
Keywords
- Product Description
-
DHS-16A Halogen moisture meter adopts HBM weighing system to ensure accurate weighing. Ring quartz tungsten halogen infrared heating source, quick drying of samples; in the drying process, the moisture content lost by the sample is continuously measured and displayed immediately. After the drying procedure is completed, the final moisture content value is locked.
It can fully meet the requirements of moisture testing in areas like food, medicine, tobacco, paper making, chemical and mineral industry and so on.
Product Features.
Product Paramenters.Model
DHS-16A
Moisture measurement range
0～100%Moisture content readability
0.01%
Moisture measurement accuracy
±0.5%
Weighing range
0～50g
Weight accuracy
0.001g
Weighing sensor
High-precision heat insulation sensor
Heating temperature range
50～180℃
Heating time
0～99min
Heating source
Halogen lamp
Display parameters
Moisture, time, temperature, weight…
Output interface
Standard with RS232 Output interface-convenient connection to printers, computers and other peripheral equipment, in line with FDA/HACCP format requirements
Input power
AC200～240V, 3A, 50Hz
Power
Max 350W in the heating process
Scale size
Diameter 100mm
Shape size
330×180×140mm
Other Models.
Model
DHS-10A
DHS-16
DHS-16A
DHS-20A
Weighing value
50g
50g
50g
110g
Moisture measurement accuracy
±0.5% (Sample≥3g)
Moisture content readability
0.02%
0.01%
Temperature control adjustment tolerance
±1℃
Heating temperature range
50～180℃
Heating time
0～99min
Heating time control
Timed / Automatic
Display parameters
9 kinds
Moisture measurement range
0-100%
Output interface
//
RS233
Scale size
Diameter 100mm
Overall dimensions
300×180×140mm
Tester weight
2.9Kg
Total weight
4.2Kg
Heating source
Halogen lamp
